• Dual ceramic ball bearing system for optimal turbo response and enhanced durability by minimizing shaft motion.
• 9 Blade G-Aero billet compressor wheel featuring extended tapered tip technology.
• 9 Blade G-Aero Inconel 713c turbine wheel.
• Anti-surge ported-shroud compressor inlet with an integrated speed sensor port.

Compressor Housing: Without Compressor Housing

Turbine Housing: Without Turbine Housing

Rotation: Reverse

• Compressor Wheel: 54*67mm
• Turbine Wheel: 60*55mm
• Compressor Outlet: 2″ Hose
• Turbine Inlet: 2.5″ V-band
• Turbine Outlet: 3″ V-band
• Water Ports: 2-M14 X 1.5
• Oil Inlet: 7/16-24 UNF with a -4AN Restrictor pre-installed
• Oil Outlet: Standard T3 Oil Drain Flange
