PRODUCT FEATURES:

- Software designed to give the user unprecedented configuration flexibility.

- The user has the ability to adjust the size of all tables in the software and the channels used on each axis of the table.

- Flexible system with custom functions, numbers, CAN inputs, well known for Power Management Unit (PMU) and Advanced Display Unit (ADU).

- PWM solenoid valve control.

- Outputs and inputs to support the most demanding applications.

- Supported engine type - Four-stroke, two-stroke, rotor; up to 12 cylinders.

- Oxygen sensor - 2 x internal LSU 4.9 controller, support for up to 4 sensors.

- 2 x DBW full support with automatic calibration.

- User defined board sizes up to 32×32.

- 2 x CAN 2.0A/B, 1 x LIN bus.

- 2x knock sensors.

- Login to external USB memory.

- Data logging up to 500 Hz.

- 8 EGT inputs (or precision analog inputs).

- A total of 46 outputs and 30 inputs.

- Custom user functions, numbers, tables and outputs.

- IP 65 waterproof housing, custom made CNC machined aluminum.

- On-line parameter analysis displayed in log graph.
