Powerlite Radial Mount
The Powerlite four piston radial mount caliper starts at 2.26 pounds with a sleek profile, superior strength, and durability in high-temperature situations. It is easily adapted to a wide range of sports, rally, and off-road driving applications.
Strength comes from a combination of process and design. The process of stress-flow forging re-aligns the metal's grain structure within the contour of the caliper body, eliminating stresses and interruptions to the internal grain structure that occur when machining a straight block billet. The FEA generated radial transition design eliminates steps and shoulders in the area between the piston housing body and the caliper bridges, incorporating a radius in this critical area to substantially increase resistance to deflection and caliper separation under load.
The Powerlite uses a new 7912 type brake pad supported from the top by Quick-clip pad retainers, eliminating the need for a pad support step in the bottom of the caliper and adding additional clearance for mounting closer to the hub on small wheel and rotor applications. The pad radius matches rotor diameters between 9.45" (240.0 mm) and 11.75" (298.5 mm), and the caliper fits easily inside many 13.00" (330.2 mm) wheel applications. The Quick-Clips also accommodate easy pad access without caliper removal. Brake pad compounds are available for the full range of sport and competition applications.
| Pistons | ||||||||
|---|---|---|---|---|---|---|---|---|
| Piston Count | 4 | |||||||
| Piston Area (in²) | 1.58 | |||||||
| Piston Type | Stainless | |||||||
| Dust Boot | No | |||||||
| Rotor Dimensions | ||||||||
| Rotor Width (in) | 0.86 | |||||||
| Rotor Diameter (in) | 11.00 | |||||||
| Pad Dimensions | ||||||||
| Pad Area (in²) | 5 | |||||||
| Pad Volume (in³) | 1.8 | |||||||
| Duty Rating & Material | ||||||||
| Material | Forged Aluminium | |||||||
| Weight (lbs) | 2.8 | |||||||
| Colors & Finish | ||||||||
| Color | Anodize | |||||||
| Finish
Universal Part: This product fits multiple vehicles (universal application).
Vehicle Compatibility
WILWOODFounded in 1977 in Camarillo, California, USA, Wilwood Engineering is a leading manufacturer of high-performance disc brake systems and components. Wilwood produces lightweight racing calipers, rotors, brake kits, and master cylinders for road racing, drag racing, off-road, and street performance, trusted by professionals worldwide.
