Technical Specifications

• Application: Chevrolet Small Block
• Type: Forged 4340 Chrome Moly Steel, engineered for racing
• Con Rods: H-beam design, 8 pieces per set
• Included Bolts: Genuine ARP 2000 bolts
• Upgrade Option: Available for ARP L19 bolts at an additional cost
• Bolts Size: 3/8" ARP 2000
• Tolerance: Balanced to +/- 1 gram per set
• Piston Bolt Hole Tolerance: ±0.004mm
• Power Rating: Supports 600hp to 800PS per set
• Fastening Strength: 220,000 to 230,000 PSI
• Torque Specification: 48ft-lbs (approximately 65 NM)
• Maximum RPM: 7000-9000 RPM

Dimensions

• Center-to-Center Length: 152.4mm (6 inches)
• Big End Diameter: 56.515mm (2.225 inches)
• Small End Diameter: 23.55mm (0.927 inches)
• Big End Width: 23.9mm (0.941 inches)
• Small End Width: 25.65mm (1.01 inches)

Product Features

Engineered for the serious racer, our performance con rods are crafted from high-grade SAE 4340 Chrome Moly Steel, ensuring unparalleled strength and durability. Each rod undergoes precision CNC machining, with both big and small ends finished using a SUNNEN honing machine for optimal performance. The design incorporates precision alignment sleeves that secure the rod cap, maintaining the integrity of the big end bore and preventing cap walk.

Every rod is subjected to rigorous quality control measures, including 100% X-ray inspection, sonic testing, and magnafluxing to guarantee reliability under extreme conditions. Multi-stage heat treatment and shot peening processes are employed to relieve stress and enhance longevity. Additionally, each set comes with bronzed bushings, perfectly suited for floating piston pins, ensuring smooth operation and performance.

Installation Note

For optimal performance and safety, professional installation is strongly recommended. Please note that installation instructions are not included.
