Technical Specifications

• Type: 4340 EN24 Forged Steel H-Beam Connecting Rod
• Quantity: 6 pieces included
• Bolts: Genuine ARP 2000 bolts included
• Optional Upgrade: ARP L19 bolts available (additional cost)
• Lubricants: Excludes ARP Ultra Torque Assembly Lubricants
• Tolerance: Balanced to +/- 1 gram per set
• Max RPM: Capable of handling up to 9000 RPM
• Warranty: One-year warranty against manufacturing defects

Application Compatibility

• Designed for Toyota Supra 2JZ 2JZ-GE/GTE Engine
• Fits Toyota Altezza AS300 and Lexus IS300 (1991-2004, 3.0L)
• Compatible with Toyota Aristo and Lexus GS300 (1998-2005, 3.0L)
• Works with Toyota Crown and Crown Majesta S140/S150 (1991-2004, 3.0L)
• Applicable for Toyota Mark II X90 (1992–1996, 3.0L) and X100 (1996–2000, 3.0L)
• Compatible with Toyota Chaser X90 (1992–1996, 3.0L) and X100 (1996–2001, 3.0L)
• Fits Toyota Cresta X90 series (1992–1996, 3.0L)
• Compatible with Toyota Progres Z30 series (1991–2000, 3.0L)
• Works with Toyota Soarer and Lexus SC300 Z30 (1991-2000)
• Designed for Toyota Supra A80 (1993–2002, 2,997 cc)
• Compatible with Toyota Aristo 3.0V JZS147 (Japan-only)
• Fits Toyota Aristo V300 JZS161 (Japan-only)
• Applicable for Toyota Supra RZ/Turbo JZA80

Dimensions

Center-to-center length: 142mm
Big end diameter: 55mm
Small end diameter: 22mm
Big end width: 26mm
Small end width: 26mm

Key Features

1. Constructed from Forged SAE 4340 Chrome Moly Steel for exceptional strength and durability, ideal for racing applications.
2. Equipped with Genuine ARP 2000 bolts, with optional ARP L19 fasteners for enhanced performance.
3. H-Beam design minimizes weight while maintaining structural integrity.
4. Heat-treated and shot-peened to eliminate stress risers and ensure consistent performance.
5. 100% CNC machined for precision, featuring rod cap alignment dowels.
6. Bores finished to a tolerance of +/- .01 mm for optimal fit.
7. Each rod is balanced within +/- 1 gram for superior performance.
8. Magnetic particle testing ensures each rod is free from defects.
9. 100% X-rayed and sonic tested for quality assurance.
